Features
◆ real time temperature information
◆ 24-hour online
◆ remote monitoring
◆ temperature alarm
◆ adapt to complex environment
Typical applications
◆ warehouse fire prevention
◆ smart raise livestock
◆ industrial control
Specifications
C2D Thermal Webcam Spec | |
Hardware | |
Sensor | 256x192 VOX Spectral Range7.4-14um |
Lens | 4/6.8mm |
Focus | Manual |
Refresh Rate | 25Hz |
Light Resolution | 2592x1520/1920*1080/640*480 |
Light lens | 4/8mm |
Network Interface | 100Mhz, Support POE (optional) |
GPIO | 1 Way GPIO output |
Weight | 1250g |
Size | 152x87x82mm |
Operation Temp | -10℃-50℃ |
Storage Temp | -20℃-50℃ |
Power Supply | 12VDC/POE |
Power Consumption | <0.5W |
Waterproof Rating | IP54 |
Mounting | 1/4" |
Measure | |
Resolution: | 256x192 |
Accuracy： | +/-3℃,+/-0.5℃(with black body) |
NETD | NEDT<0.10℃ |
Measuring Range | -20℃-120℃,-20℃-400℃(option) |
NUC | Shutter |
Software | |
Operation Mode | Night vision, Temp measurement, Temp alarm |
output | Picture, Video |
Measure Mode | 5 Areas+5 lines+5 Points |
Color Palette | White hot/Black hot/Multiple color options |
Alarm Mode | Email FTP GPIO |
Network Protocol | Onvif Rtsp |
Authority | WS-Username token, http Digest |
Time Configuration | Auto/Manual |
Configuration | WEB |
IP Configuration | Manual, DHCP |
NVR | Support |
SDK | Windows and Linux |
