Features
◆ large zoom lens
◆ outdoor PTZ
◆ 24-hour online
◆ remote monitoring
◆ adapt to complex environment
Typical applications
◆ forest fire prevention
◆ port
◆ security
◆ electricity
Specifications
H2/H6 Thermal Webcam Spec | |
Hardware | |
Sensor | H3:384x288 H6:640x480 Spectral Range7.4-14um |
Lens | 5-100mm |
Focus | Manual/Auto |
Refresh Rate | 25Hz |
Light Resolution | 2592x1520/1920*1080/640*480 |
Light lens | 5-50mm |
Network Interface | 100Mhz, Support POE (optional) |
GPIO | 1 Way GPIO output |
Weight | 7750g |
Size | 280x200x182mm |
Operation Temp | -10℃-50℃ |
Storage Temp | -20℃-50℃ |
Power Supply | 12VDC/POE |
Power Consumption | <10W |
Waterproof Rating | IP65 |
Measure | |
Resolution: | 384x288/640x480 |
Accuracy： | +/-3℃ |
NETD | NEDT<0.10℃ |
Measuring Range | -20℃-150℃ |
NUC | Shutter |
Software | |
Operation Mode | Night vision, Temp measurement, Temp alarm |
output | Picture, Video |
Measure Mode | 5 Areas+5 lines+5 Points |
Color Palette | White hot/Black hot/Multiple color options |
Alarm Mode | Email FTP GPIO |
Network Protocol | Onvif Rtsp |
Authority | WS-Username token, http Digest |
Time Configuration | Auto/Manual |
Configuration | WEB |
IP Configuration | Manual, DHCP |
NVR | Support |
SDK | Windows and Linux |
